Lab Notes:

1. On all IOS devices (routers and switches) load the preconfiguration file from flash: memory titled, “Lab-3-Begin”.

2. Once you perform the step above the following will be preconfigured for you:

   • All IPv4 addressing on devices other than PCs as shown in the IPv4 addressing chart
   • Telnet will be preconfigured on R1 and R2
   • VLANs and 802.1q VLAN Trunks
   • Router interfaces will be administratively up.
   • Devices will have pre-configured Enable passwords of “cisco”

If you get stuck at any point during this lab and wish to view the Lab Solution, load the pre-configuration file (on any IOS device) named, “Lab-3-Solution” from flash memory.
